campus hutthurm

• EXRE - Applied exoskeleton research for use in rehabilitation. The project aims to improve synergies between the regions in applied research. An international, interdisciplinary research team is driving the development of an exoskeleton prototype for rehabilitation and prosthetic practice.
  Joint innovations in the fields of design, construction technologies, 3D printing, mechatronics, applied cybernetics (brain-computer interface) and rehabilitation will be utilised. The participation of 5 associated partners from the field and the testing of the exoskeleton enable a transfer of expertise to SMEs in the fields of mechatronics, rehabilitation and prosthetics.
  Partner: University of West Bohemia: ZČU in Pilsen
• SWEFTD - Development of an interdisciplinary approach to early tumour detection.
  The aim of the project is to improve tumour detection through innovative data analysis. By combining the different approaches of medicine and engineering, a unique added value is created that opens up new perspectives.
  The project also serves as a basis for future research projects and funding in the field of early tumour detection
  Associated partners: University of Regensburg
• Sim3dApp - Understanding materials and processes with automated reworking strategies using digital twins and simulation in FFF printing
  The aim of the project is to develop an FFF printer that works primarily in the high-temperature range in order to process materials such as PEEK and fibre-reinforced polymers. With an integrated monitoring system consisting of various sensors, such as thermal cameras, the component history is recorded and defect monitoring is guaranteed. The real-time data generated is collected in a database and used for forecasting via AI algorithms. In the event of deviations, the system independently intervenes in the printing process and adjusts parameters accordingly or cancels the print. Simulations are used in parallel to supplement training data and make predictions even before the process starts.
  Partner: Reimann Industrietechnik GmbH

• SensoTwin - Sensor-integrated digital twin for high-performance fibre composite applications
  Partners: TC Freyung, TUM, TÜV Süd Industries Service GmbH, Enercon, Fos4x, UL International GmbH
• HiPower - Industrial research and construction of a prototype for a novel 100W high power solar panel subsystem for New Space NanoSats and SmallSats
  Partner: Deployables Cubed GmbH
• AutoClean - Development of an automated post-processing line with integrated AI-based quality control and sorting station
  and sorting station for components from powder bed-based 3D printing
  Partners: TC Cham, SHL Automatisierungstechnik AG, thinkTEC3D GmbH
• Smart3D - Smart 3D printing of high-performance polymer systems
  Partners: TC Grafenau, Ingenieurbüro Muhr GmbH, Kumovis GmbH, nebumind GmbH
• Powercube - Deployables Cubed GmbH - This project is about the development of a mini-satellite, which should deliver a power of 100W until the end of the mission. Furthermore, the structure is to be designed in such a way that it can be stowed in the volume of a cube with an edge length of 10 cm, can be transported safely, unfolds easily at the mission target and does not weigh more than two kilograms. In order to comply with the specified boundary conditions, the implementation of an integral fibre-reinforced carrier structure with innovative joints is being investigated. Deployment simulations and tests are being carried out to validate the concepts.
• SurfMod3Dton - Functionalisation of 3D (FDM) components for detonation coating
  Partner: Reimann Industrietechnik GmbH
• Sumida Components & Modules GmbH - Effective chain analysis for injection moulded parts in high-performance electronic components In cooperation with Sumida, the Technology Campus Hutthurm is developing a simulation strategy to transfer the results from the injection moulding simulation to a structural simulation. The subsequent FE calculation is intended to optimise the load-bearing behaviour while simultaneously improving the component design.
• ForCEs - Exoskeleton research cluster - cyber-physical systems for the working world of the future
  Partners: TC Freyung, TC Cham

3D coordinate measuring machine (3d scanner)

The optical 3D coordinate measuring machine of the VL series captures complex shapes and geometries of any measured object with the help of fringe projection images. 16 million measuring points enable the determination of form and position tolerances as well as plane, profile, profile comparison and 3D comparison measurements. In addition, the highly accurate acquisition of measured objects in conjunction with the latest software enables CAD data feedback to be performed in order to generate and edit virtual 3D models.

• Technical data

horizontal single-sample dilatometer dil 801

With our fully automatic and highly precise horizontal single-sample dilatometer, a sample can be measured over a temperature range from -90°C to 450°C in a defined atmosphere. The results from the temperature-dependent dimensional changes can be used for quality assurance and basic research for process simulation.

• Technical data

discovery dma 850

Dynamic mechanical analysis (DMA) can be used to assess the mechanical properties of materials as a function of temperature, time or humidity. By measuring the elastic and viscous properties, complex materials such as polymers and composites can be described for process simulation and, for example, the glass transition temperature of polymers can be determined.

• Technical data

discovery dsc 250

DSC (Differential Scanning Calorimetry) is used to determine the amount of heat generated or released by a sample during heating or cooling. This enables the determination of characteristic material values (e.g. phase transitions, specific hear capacity), especially for filled and unfilled polymers, technical high-performance polymers and fibre-reinforced polymers according to DIN EN ISO 11357-1 to -7. These determined results form the basis for process simulations.

• Technical data

hr-20 discovery hybrid rheometer

The rheometer is used to investigate material-specific deformation and flow behaviour and serves as a basis for process simulation. Flow tests, time-dependent measurements to determine creep behaviour and stress relaxation, but also vibration tests can be carried out. The viscosity and yield point are determined in order to gain a better understanding of the processability of polymers.

• Technical data

dynamic materials testing machine hc 100 kn

The Dynamic Materials Testing Machine is used to determine characteristic material values, in particular of filled and unfilled polymers and technical high-performance polymers as well as fibre composite polymers. These obtained values are required both as a basis for construction and design tasks (e.g. of lightweight structures and generally as input for simulations) and for the relative evaluation of different materials in the context of material selection.

• Technical data

WDD- PLANT

Determination of the water vapour transmission rate of films and foils for samples with a thickness up to 25mm.

• Technical Data

Bulk density measurement

Determination of the apparent density of moulding compounds according to DIN EN ISO60

• Technical Data

grinding and polishing machine

Mechanical processing, from cutting larger components to grinding and polishing samples. grinding and polishing of ground samples.

• Technical Data

microscopy

Imaging for fracture analyses, texture analyses and morphology with large-area scans
and extensive evaluation options (e.g. fibre volume content). Combined with
dark field, polariser and comprehensive software, the microscope offers a range of analytical
optical examination, the microscope also offers a range of analysis and evaluation functions.
In addition, the heating/cooling table can be used to investigate the material behaviour during temperature changes (e.g. melting).
(e.g. melting, crystallisation, dissolution and precipitation processes, formation of spherulites)
at cryogenic temperatures up to 600°C can be examined.

• Technical Data

3d printer raise3d pro2

Our 3D printer uses the Fused Filament Fabrication (FFF) process. Through integration of sensor technology during the printing process, the functionalisation of 3D printed components can be advanced. Thus, it is possible to derive material-process-property relationships in order to increase the overall performance of additively manufactured components.

• Technical data

mini extruder with film blowing unit

Laboratory production trials for standard plastic pellets up to max. 300°C for strand extrusion and blown film production.

• Technical data

composite processing station with oven and resin/reaction
injection molding/ rim plant

Resin injection plant for the production of fiber composite and pure plastic specimens (shoulder,
short, long samples). Processing of low-pressure injectable resin systems in interaction
with fiber semi-finished products such as woven fabrics and scrims made from a wide variety of fiber materials.

• Technical data
